High Temperature Wire And Cable Extrusion Line With Material FEP FPA ETFE
Product Details:
| Place of Origin: | China |
| Brand Name: | Wirecan |
| Certification: | ISO9001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | By negotiation |
| Packaging Details: | Plastic film+wooden box |
| Delivery Time: | Min.50working days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Up to different machine |
|
Detail Information |
|||
| Usage: | High Temperature Wire And Cable Extrusion | Material: | FEP/PFA/ETFE/PVDF |
|---|---|---|---|
| Voltage: | 380V 50HZ/60HZ | Screw Material: | GH113 |
| Screw L/D Ratio: | 25:1 | Warranty: | One Year Warranty And Lifelong Maintenance |
| High Light: | High Temperature Cable Extrusion Line,FEP Cable Extrusion Line |
||
Product Description
High Temperature Wire And Cable Extrusion Line With Material FEP ,FPA,ETFE
i-suntop Electric wire and cable equipments2022022...
1. Usage for High Temperature Wire And Cable Extrusion Line :
Use for extruding high temperature wire cable with material FEP,PFA,ETFE /PVDF etc
2. Specification for High Temperature Wire And Cable Extrusion Line :
| SJ25 | SJ30 | SJ35 | SJ45 | SJ50 | SJ65 | |
| Finished diameter | 0.1-1.8mm | 0.28-2.0mm | 0.4-3.0mm | 0.6-4.0mm | 0.6-5.0mm | 5.0-35mm |
| Line speed (max.) | 150m/min | 180m/min | 180m/min | 150m/min | 150m/min | 80m/min |
| Extrusion output (max.) | 8kg/h | 20kg/h | 25kg/h | 50kg/h | 60kg/h | 100kg/h |
| L/D | 25:1 | 25:1 | 25:1 | 25:1 | 25:1 | 25:1 |
| Extruder power | 4KW | 11KW | 11KW | 15KW | 15KW | 22KW |
| Capstan wheel | Φ300 (belt type) | Φ300(belt type) or Φ191 (dual wheel) | Φ318 (dual wheel) | Φ400 (dual wheel) | Φ500 (dual wheel) | Caterpillar type |
| Payoff reel | PN 200-300 | PN 200-300 | PN 300-400 | PN 400-500 | PN 400-630 | PN800-1250 |
| Take-up reel | PN 200-400 | PN 300-400 | PN 300-400 | PN 400-630 | PN 500-630 | PN1000-1600 |
3.Technical advantage (technology wins the market)
- We committed ourselves to the R & D and manufacturing of silica gel equipment and wire and cable equipment, with rich experience
- Provide customers with solutions for various stages of silicone hose, wire, profile and cable production process, improve the equipment according to customers' products, and provide customers with the best equipment.
- Provide customers with one-stop services such as plant planning, whole plant equipment investment planning, selection and allocation of developers and staff operation technology training.
- New product development and certification technical support services. Our technicians are familiar with the production process of various silica gel products and national wire standards, the performance of various silica gel raw materials, and the development and certification of various electronic wires, silica gel wires, network wires, HDMI wires, power wires, Teflon wires, rubber wires and other products
- With strong market share and good reputation, our company has gathered a large number of information about silica gel, cable materials and various conductors to provide good, most affordable and most convenient investment services.
