Computer Controlled Indoor And Outdoor Fiber Optic Cable Tensile Test Equipment
Product Details:
| Place of Origin: | China |
| Brand Name: | I-suntop |
| Certification: | SGS |
| Model Number: | GFK-50/GFK-100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | By negotiation |
| Packaging Details: | Plastic film+wooden box |
| Delivery Time: | Min.30working days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | Up to different machine |
|
Detail Information |
|||
| Product Name: | Computer Controlled Fiber Optic Cable Tensile Testing Equipment | Application: | Optic Fiber Testing |
|---|---|---|---|
| Standards: | IEC60794-1-2 | Color: | Customized |
| Wavelength: | 1310/1550nm | Warranty: | 1 Year |
| Operating Temperature: | +25-35 Degree Centegrate | Power Supply: | 220v |
| High Light: | Outdoor Optical Cable Tensile Tester,Indoor Optical Cable Tensile Tester,Fiber Optic Cable Test Equipment |
||
Product Description
Computer Controlled indoor and outdoor Fiber Optic Cable Tensile Test Equipment
I-suntop Optical cable mechanical testing equipmen...
1. Application of Fiber optic cable tensile test equipment
The optical fiber cable mechanical performance testing machines include tension, crush, impact, torsion, repeated-bending, flexing, winding, abrasion etc. It can meet the IEC-60794-1-2 testing requirement for optical fiber cable.Each testing machine can be operated of all function which by microcomputer controlled. It can be remote controlled by computer through communication port.
2. Main Technical Specifications of Fiber optic cable tensile testing equipment
| Item | spec. |
|
Product model |
GFK-50/GFK-100 |
|
Max load |
50kN/100kN |
|
Load measurement range |
(1%~100%) F.S. |
|
Load resolution |
±250000 yard,no stepping, no change in full scale,resolution unchanged |
|
Load accuracy |
±0.5% |
|
Load duration |
≥3 Hours, set arbitrarily |
|
Load hold accuracy |
±0.5% |
|
Deformation measurement gauge length |
1000mm |
|
Deformation measurement range |
(0-50) mm |
|
Deformation resolution |
0.001mm |
|
Deformation accuracy |
±0.5% |
|
Displacement resolution |
0.001mm |
|
Displacement control resolution |
0.000015mm |
|
Displacement accuracy |
±0.5% |
|
Displacement speed range |
(0.01～500) mm/min,set arbitrarily |
|
Displacement speed accuracy |
±0.5% |
|
Tension space |
25m |
|
Distance of run |
1000mm |
|
Max diameter of clamping optical cable |
30mm |
|
Equipment weight |
About 3.5T |
3. Installation requirements of Fiber optic cable tensile testing equipment
- Host power supply: single phase, AC220V±10%, 50～60Hz, 2kW.
- Computer power supply: single phase, AC220V±10%, 50～60Hz, 0.5kW.
- Install onto a stable base, levelness≤0.2/1000, and room of more than 1 m around.
- Ambient temperature: 25℃±10℃, humidity: ≤80% non-condensing.
- No vibrating or corrosive media indoor.
